12 | ORBEA
Failure to follow the recommendations out-
lined in this manual and riding a bicycle that
shows any of the symptoms described above
may cause accidents and serious injuries.
TIGHTENING TORQUES. Always check the
tightening torques and install the compo-
nents described in this manual according
tions for components from other manu-
facturers installed on your Orbea bicycle.
lead to a malfunction of the components,
accidents and even death.
M AI NTEN ANCE P E RI O DS
OF COM P ONENTS
The component maintenance periods indi-
cated below are for reference, and depend
largely on factors such as the weather con-
ditions (adverse conditions considerably re-
duce the life of the components and main-
tenance times), cleanliness of the bicycle
and its components (components with ac-
cumulated dirt wear out more quickly) and
use (more demanding use of the bicycle will
require shorter maintenance periods).
For components from other brands mounted
on Orbea bicycles, you can check the recom-
mended or mandatory maintenance periods
on the manufacturer's website or by contact-
ing that brand's dealer in your country.
Damage to components as a result of failing
to follow the recommended maintenance
periods could result in damage that is not
covered by Orbea's or the manufacturer's
warranty.
Failure to comply with maintenance periods
could result in damage to the components
and lead to malfunctions and accidents.
TECHNICAL MANUAL
HEADSET:
· Inspection of its operation before every ride.
· Manual disassembly and inspection of the bearings af-
ter every 6 months of use.
BOTTOM BRACKET:
· Inspection of its operation before every ride.
· Manual disassembly and inspection of the bearings af-
-
ter every 6 months of use.
DRIVETRAIN:
· Inspection of its operation before every ride.
· Regular inspection of chain wear every 500 km. A
chain that is worn beyond the manufacturer's recom-
mendations must be replaced to prevent damage to
the rest of the drivetrain components. Failure to follow
the manufacturer's recommendations for wear could
necessitate the replacement of the rest of the parts of
the drivetrain.
WHEELS:
· Inspection of its operation before every ride.
· Disassembly and manual inspection of the bearings and
all components every 6 months.
SHOCKS AND SUSPENSION FORKS:
· Inspection of its operation before every ride.
· Inspection and full maintenance every 125 hours or
er's authorised dealer.
DROPPER SEATPOSTS:
· Inspection of its operation before every ride.
· Inspection and full maintenance every 125 hours or
er's authorised dealer.
PIVOT POINTS ON FULL SUSPENSION FRAMES:
· Inspection of its operation before every ride.
BLUE PAPER RISE CARBON · 20 2 3
· Disassembly of the frame and manual inspection of all
bearings every 125 hours of use or once a year (which-
ing to the conditions in which the bicycle is ridden.
More demanding use of the bicycle or use in adverse
weather or in mud requires the disassembly and inspec-
does not turn smoothly or has excessive play, it must
be replaced immediately.
GEAR CABLES AND HOUSING:
· Inspection of its operation before every ride.
· Replacement of gear cables every 6 months to 1 year
depending on the bicycle's usage conditions.
BRAKES:
· Inspection of the operation and wear of the brake pads
or inserts before each ride.
· Check the wear on disc brakes and the cables or hy-
draulic lines every 6 months to 1 year depending on the
conditions under which the bicycle is used. Flush the
hydraulic lines once a year.
ELECTRICAL ASSIST SYSTEM COMPONENTS:
Regularly check the connections and cables of the elec-
tric assist system components on your bicycle. The con-
nections must be clean and free from foreign objects.
The cables must be in good condition and not have any
cuts or kinks that could cause short circuits and loss of
- electrical assist. The exterior of components such as re-
mote controls and batteries must show no damage that
would allow water or other items to enter.
If there is any damage at all to the electrical components,
go to your Orbea dealer for diagnosis and/or replacement.
- Consult the section of this manual enti-
tled "Warnings on the Use of the Electri-
rectly care for its components.
UPDATES TO THE ELECTRICAL SYSTEM:
- Ebike electrical assist systems can have improvements or
updates that improve the operation of the system. Some
is always advisable to disable the connection
to mobile networks and WiFi to prevent an
incoming call or message from interrupting
the update. If the update is interrupted and
this causes the bicycle to malfunction, take
it to an authorised Orbea dealer to have the
update performed using the Shimano SM-
found here:
Other updates may need to be performed by an authorised
dealer. Remind your dealer to check for any available up-
dates for your bicycle when you bring it in for maintenance
or repairs.
Some of these checks and maintenance
requirements go beyond the mechanical
knowledge of most bicycle users. If you
maintenance, always go to an Orbea dealer
for the maintenance of your bicycle and its
components. Failure to perform proper main-
tenance can result in malfunctions and acci-
dents with serious consequences.
Incorrectly performed maintenance can dam-
age the components, which are not covered
by the warranty.
-
