114 | ORBEA
RANGE EXTENDER SPARE PA RTS
53
49
49
RS RANGE EXTENDER 252WH GEN2
ART No.: Y045
Includes everything required for installing
the Range Extender battery
· 252Wh Gen2 Range Extender battery
· Range Extender bottle holder mounting
· Rubber protections
· Charging port connection cable
· Rubber safety band
51
RANGE EXTENDER GEN0/GEN1/GEN2 MOUNTING
Compatible with standard bottle
ART No.: X223
29.1 Range Extender Gen0/Gen1/Gen2 bottle
holder mounting
29.2 Rubber protectors
29.3 Rubber safety band
5 3
RI S E B OTT LE H O LD E R B OLT K I T
ART No.: XA80
53.1
53.2 Washer 6.2x10x2
TECHNICAL MANUAL
52
51
50
50
RANGE EXTENDER GEN1/GEN2 225mm CONNECTION CABLE
Q UANT.
ART No.: XA86
Range Extender Gen1/Gen2 225 mm
connection cable
1
1
6
1
1
5 2
RANGE EXTENDER RUBBER SAFETY BAND KIT
QUA NT.
ART No.: X224
Rubber safety band 40x3.5
1
6
1
QUANT.
2
4
BLUE PAPER RISE CARBON · 20 2 3
28 RS 2A- 4 A G E N2 S M A RT C HA RG E R
COMPATIBILITY NOTICE. GEN2 ELECTRICAL SYSTEM
COMPONENTS
The Orbea electrical system components (internal battery
-540Wh or 360Wh-, Range Extender, cable harness and
with Rise, Kemen or Urrun models from ranges prior to
2023 with Orbea Gen0 and Gen1 electrical system com-
ponents. These Orbea Ebike Systems components from
the 2023 range are designed to guarantee compatibility
components.
Do not use the Gen2 charger to charge batteries from pre-
vious Orbea systems.
TECHNICAL SPECIFICATIONS OF THE RS 2A-4A GEN2 SMART CHARGER
QUANT.
INPUT
1
OUTPUT
INTERNAL BATTERY RS 540WH CHARGING CURRENT
RANGE EXTENDER RS 252WH CHARGING CURRENT
CHARGING TEMPERATURE RANGE
CHARGE DISPLAY
QUANT.
4
CERTIFICATIONS
COMPATIBILITY
ORBEA | 115
100-240V. 50-60HZ. AC
42V 4A DC
4 A
2A
The Smart Charger RS recognises which battery is connected
and adapts the charging current.
Charging process and errors display LED
CE: EN60335-1, EN60335-2-29
RCM, SAA: AS/NZS 60335.2.29
CE: UKCA-EN55014-1/2, EN610003-3/2
Compatible with RS Gen2 systems on Orbea models with
E N
