USE OF THE ORBEA RS TOOLBOX

The Orbea RS Toolbox is not compatible
with the simultaneous use of the native
Garmin Edge Shimano STEPS application
in Edge 530, 830, 1030 and 1030 Plus
devices.
Toolbox, disconnect or remove the bicycle
from your Garmin device's sensor list. This
limitation does not depend on the Toolbox
but is put in place by Garmin.
CONNECT YOUR BICYCLE TO THE ORBEA RS TOOLBOX
RS Toolbox screen and then turn on your bicycle so that the
remaining battery data appears in Toolbox right away. Oth-
erwise, the remaining battery level will be displayed once a
certain distance has been ridden and the battery level has
When Toolbox is started up, it will connect to the bicycle
with the strongest signal (usually the closest) and once
connected will pair permanently with that bicycle. If you
experience connection problems, make sure that your
bicycle is the only one that is turned on to facilitate the
connection.
TECHNICAL MANUAL
Your bicycle connects automatically to Orbea RS Toolbox
try pressing the buttons to change the assist level. If the
Toolbox data are still not visible, turn the bicycle off and on
again to reset the connection.
YOUR BICYCLE'S VISIBLE DATA IN ORBEA RS
TOOLBOX
ASSIST MODE: Displays the system's current assist mode
from among the four available modes: Off, Eco, Trail,
· Assist mode display options (on wristband devices):
Orbea RS Toolbox allows the selected assist mode to be
displayed in two ways. See the Customisation of Data
Fields section for the information selection method for
. You can select the assist mode view by selecting it
the name of the current assist level will be displayed.
. It is also possible to view the selected assist modes
using the external circular Toolbox line. When an assist
mode is selected, the corresponding portion will be
highlighted. The colour codes are:
BLUE PAPER RISE CARBON · 20 2 3
Walk Assist selected but not active
GREEN: Walk Assist operating.
YELLOW: Eco
ORANGE: Trail
RED
Eco
Walk Assist Trail
Active
Walk Assist
Boost
BATTERY:
If an external Range Extender battery is connected, the
system will take into account the total combined capacity
of the internal battery and the Range Extender and the
Toolbox will display the remaining battery percentage, ta-
king into account the charge of both batteries.
If the remaining battery percentage is not vi-
sible in the Orbea RS Toolbox during cycling,
it will become visible again when the remai-
communicate the battery level to the Garmin
vel will be displayed on the unit.
ASSIST LEVEL: The motor's electrical assist delivery level,
depending on the current assist mode. It is displayed as a
percentage of the total available motor power.omo porcen-
taje de la potencia total disponible del motor.
· Assist level display options on wristband devices:
Orbea RS Toolbox allows the current assist level to be
displayed in two ways. See the Customisation of Data
Fields section for the information selection method for
. You can select the motor assist level view using the
external circular line of the Toolbox. In this case, the
assist level will be displayed by a black line running
the different assist modes will allow access to cer-
tain motor power zones. For example, only the most
powerful assist modes will allow the motor to deliver
41%-60%
21%-40%
Current assit
1%-20%
power delivery
. It is also possible to view the assist level through the
as a percentage of the motor's total available power.
Eco
Walk Assist Trail
Active
Walk Assist
-
RANGE: Range (in km or miles) in assist mode and cu-
rrent battery level. This data will change depending on
the power delivered by the rider, and also takes into ac-
count the previous use of the bicycle.
SPEED: The bicycle's current speed.
RATE: The cyclist's pedalling rate.
ORBEA | 41
E N
61%-80%
81%-100%
Boost
