3 2 SU SP EN S I ONS

A DJ U ST ING T HE FO R KS
See the full manual for Rise-mounted forks in the manufacturer's documentation.
FOX
Fox main manuals page:
Fox 36 2023 Float Factory Grip 2 150 mm fork manual
Fox 34 2022 Float Performance Grip 140 mm fork manual
Fox 34 2022 Float Factory FIT4 140 mm fork manual
FOX FORK SAG AND AIR PRESSURE
ADJUSTMENT SUGGESTIONS
The following tables give approximate values, they may
vary depending on the riding style and terrain conditions.
RECOMMENDED SAG MEASUREMENTS
Fox 34 Float
Fox 36 Float
TECHNICAL MANUAL
15% SAG 20% SAG
Fork total travel
(Firm) (Soft)
140mm 21mm 28mm
150mm 23mm 30mm
BLUE PAPER RISE CARBON · 20 2 3
RECOMMENDED SAG ADJUSTMENT STARTING AIR PRESSURE
FOX 34 FLOAT
Weight of rider Weight of rider Air pressure
+ gear (kg) + gear (lb) (psi)
54-68 120-150
68-82 150-180
82-95 180-210 92-102
95-113 210-250 106-120
FOX FORK AIR VOLUME ADAPTERS
You can adjust the progressiveness of your fork's air cham-
ber with volume reducers, which can be purchased at an
authorised Fox dealer.
Fox 34 Float
Fox 36 Float
ORBEA | 133
FOX 36 FLOAT
Weight of rider Weight of rider Pressure
+ gear (kg) + gear (lb) (psi)
54-59 120-130 66
59-64 130-140
64-68 140-150
150-160
82
86
82-86 180-190 89
86-91 190-200 94
91-95 200-210 99
95-100 210-220 105
100-104 220-230 109
104-109 230-240 113
109-113 240-250
Maximum No of
Travel
reducers
140mm 1 5
150mm 2
