86 | ORBEA

24 ELECTRICAL ASSIST SYSTEM COMPONENTS

Installation of power assist system components
requires advanced knowledge and may be beyond
dealer for the diagnosis, repair and installation of
the components of the Rise electrical system.
Damage to components resulting from incorrect
installation could void the warranty on those com-
ponents.
COMPATIBILITY NOTICE. GEN2 ELECTRICAL
SYSTEM COMPONENTS
The Orbea electrical system components (internal
battery -540Wh or 360Wh-, Range Extender, cable
are not compatible with Rise, Kemen or Urrun
models from ranges prior to 2023 with Orbea
Gen0 and Gen1 electrical system components.
These Orbea Ebike Systems components from the
2023 range are designed to guarantee compati-
Shimano Gen2 components. See the Orbea Ebike
compatibility of all Orbea components with our dif-
ferent bicycle models.

COMPONENT CONNECTION DIAGRAM

the stem changes depending on the mounting option
with or without a Shimano display and with mechanical
or electronic drivetrain. All assemblies use a 1200 mm
ing standard.
See the images in this section for the components used, as
well as the wiring of each component, for each option type.
TECHNICAL MANUAL
Option 1: With Shimano SC-EN600 display / mechanic transmission
SC-EN600
7
SW-EN600-L
8
3
700mm
EW-SD300
direct from motor
inside handlebar
Option 2: Without Shimano SC-EN600 display / mechanic transmission
SW-EN600-L
EW-JC302
inside stem
8
5
700mm
3
EW-SD300
inside handlebar
direct from motor
Option 3: With Shimano SC-EN600 display / electronic transmission
10
SC-EN600
7
SW-EN600-L
700mm
EW-SD300
8 3
700mm
3
EW-SD300
direct from motor
inside handlebar
Option 4: Without Shimano SC-EN600 display / electronic transmission
700mm
3 10
SW-EN600-L
EW-SD300
8
6
700mm
EW-SD300
inside handlebar
direct from motor
EW-JC304
3
inside stem
-
BLUE PAPER RISE CARBON · 20 2 3
EW-SD300
14
EW-SD300
12
540 Wh. Gen2
SW-M8150-IR
360 Wh. Gen2
EW-SD300
13
1200mm
EW-SD300
SW-M8150-IR
EW-SD300
Gen2
15
16
18
17
2
1
SEE THE LIST OF COMPONENTS AT THE
END OF THIS SECTION
ORBEA | 87
E N
19
760mm
EW-SS301
9
SEE CENTERLOCK
900mm
EW-SD300
RD-M8150-12
4
11
Electronic transmission option
