27 RANGE EXTENDER RS 252WH GEN2

The Orbea Range Extender external battery connects to
the assist system to provide 252 Wh of additional capac-
ity to it. The total capacity of the system will depend on
the capacity of the bicycle's internal battery.
Refer to the RS battery maintenance, usage,
charging and storage recommendations in
the sections of this manual entitled "Main-
tenance" and "Warnings on the Use of the
Electrical Assist System" of this manual.
See also the process for charging, switching
on and checking the level of the batteries in
the "Using the Rise" section of this manual.
See the section "Relevant information about
RS batteries" on access and for more useful
information about using and caring for the
internal battery and Range Extender.
EXTERNAL BATTERY RANGE EXTENDER RS 252Wh Gen2
VOLTAGE
CAPACITY
WEIGHT
CELLS Lithium ion. Samsung 18650
CHARGING TIME TO 100% (2A)
With RS Smart Charger
ASSEMBLY
Range Extender cable Gen1/2 to Rise Carbon charging
CONNECTION
SEALING
ISO13849 > ISO13849-1:2015
CERTIFICATIONS
UN 38.3
Compatible with Orbea Ebike System Gen2 systems on
COMPATIBILITY
2023 range onwards
TECHNICAL MANUAL
COMPATIBILITY NOTICE. GEN2
ELECTRICAL SYSTEM COMPONENTS
The Orbea electrical system components
(internal battery -540Wh or 360Wh-, Range
Extender, cable harness and Smart Charger)
Rise, Kemen or Urrun models from ranges
prior to 2023 with Orbea Gen0 and Gen1 elec-
trical system components.
These Orbea Ebike Systems components from
the 2023 range are designed to guarantee
motors, and Shimano Gen2 components.
See the Orbea Ebike Systems Compatibility
Orbea components with our different bicycle
models.
36 V
252 Wh
Approx 1.5 Kg
3.5 hours
port. 225 mm
BLUE PAPER RISE CARBON · 20 2 3
MOUNTING THE RANGE EXTENDER
downtube of your Orbea compatible bicycle, by installing
the attachment bolts with a tightening torque of 5Nm.
When installing the Range Extender bottle holder, remove
the washers pre-mounted on the frame and check that,
once installed, the six contact points of the bottle holder
are correctly supported by the downtube.
3
5 N.m
ORBEA | 109
x6
Install the Range Extender battery in the bottle holder and
secure it with the rubber safety band.
The Range Extender mounting is compatible with the
use of standard bottles when the Range Extender is
not mounted on the bicycle.
