66 | ORBEA

1 3 MAIN SWINGARM PIVOT POINT

Always follow the recommended
torque settings.
Do not use grease
GREASE
on the thread
GREASE
16.7
16.6
16.5
16.4
GREASE
16.3
16.2
16.1
1 6 RISE-OCCAM M MAIN PIVOT POINT HARDWARE KIT
ART No.: X214
16.1 Expander bolt M5x20
16.2 Expander washer 5x8x0.5
16.3 Main axle expander cone
16.4 Main pivot point axle
16.5
16.6 O-ring seal 16x2
main pivot point bushing
TECHNICAL MANUAL
GREASE
17.2
17.1
17 RISE-OCCAM M MAIN PIVOT POINT BEARING KIT
Q UANT. ART No.: X215
1
1 Enduro Max 6802 15x24x5 bearing
1
1
1
1
1
BLUE PAPER RISE CARBON · 20 2 3

1 4 LINKAGE

LINKAGE ASSEMBLY
TIGHTENING TORQUES AND MOUNTING COMPOUNDS
Do not use grease
on the thread
Do not use grease
on the thread
GREASE
6
12 N.m
GREASE
C
A
B
GREASE
5
C
10 N.m
GREASE
See LOCKR
section
Do not use
grease
on the thread
Q UANT.
1
1
Always follow the recommended
torque settings.
GREASE
5
10 N.m
C
GREASE 4
4 N.m
B
C
A B
5
15 N.m
D
GREASE
B
1 2
GREASE
C
4
5
10 N.m
5
10 N.m
Attachment of seatstays
ORBEA | 67
E N
A
Inwards Outwards
3
4
5
4 N.m
15 N.m
D
5
6
12 N.m
Installation of the shock yoke
