Orbea BLUE PAPER RISE CARBON 2023 Manual Tecnico página 70

138 | ORBEA
FOX FLOAT DPS AND FLOAT X COMPRESSION
AND REBOUND ADJUSTMENT SUGGESTIONS
RECOMMENDED REBOUND AND COMPRESSION SETTINGS
Based on air pressure once target SAG is reached
FOX FLOAT DPS
Recommended
Air pressure Air pressure
rebound
(psi)
setting (clicks)
<100 Abierto
100-120 11
120-140 10
140-160 9
160-180 8
180-200
200-220 6
220-240 5
240-260 4
260-280 3
280-300 Cerrado
INNER SPRING VOLUME REDUCERS ON FOX
SHOCKS
You can adjust the progressiveness of your shock's air
chamber with volume reducers, which can be purchased
at an authorised Fox dealer.
FOX FLOAT DPS REDUCER CONFIGURATION
Size
volume
210x55 0.2
FOX FLOAT X
Recommended
Low speed compression
rebound
(psi)
setting (clicks)
<100 10
100-120 10
120-140 9
140-160 8
160-180
Turn the dial clockwise to increase
180-200 6
clockwise to decrease compression
200-220 5
220-240 4
240-260 3
260-280 2
280-300 1
FOX FLOAT X REDUCER CONFIGURATION
Size
volume
210x55 0.3
vered from Orbea with a 0.4 reducer to customise your
the manufacturer's manual.
TECHNICAL MANUAL BLUE PAPER RISE CARBON · 2023
INNER SPRING VOLUME REDUCERS
ON FOX SHOCKS
the air chamber to achieve the progressiveness that best
suits your riding style.
LSC
WITH REDUCER 0.3
WITH REDUCER 0.4
(soft).
1. To install or remove the volume re-
ducers from the shock air chamber,
completely vent the air from the
Fox FLOAT X shock air chamber.
3. Remove the 0.3 air chamber redu-
cer from the stem and install the
Maximum reducers
volume
the air chamber without a volume
reducer.
1.0
-
This shock is delivered from the factory with a 0.3 volume
reducer, but a 0.4 volume reducer is also included so you
can modify it to your liking.
NO REDUCER MORE LINEAR BEHAVIOUR
GREATER PROGRESSIVENESS
GREATER PROGRESSIVENESS
2. Next, unscrew the lining of the air chamber from the head of the shock
absorber and slide the lining downwards.
4. Slide the air chamber lining up-
wards and securely screw it into
the head of the shock.
Fox Float X shock spacer compatibility guide:
This shock is delivered from the factory with
a 0.3 volume reducer, but a 0.4 volume re-
ducer is also included so you can modify it
to your liking.
ORBEA | 139
EN
LIGHT RIDER WEIGHT
LESS AGGRESSIVE STYLE
MEDIUM RIDER WEIGHT
MEDIUM RIDING STYLE
HIGH RIDER WEIGHT
AGGRESSIVE RIDING STYLE
5. Use a suspension bellows to re-in-
-
red pressure.
