CABLING OF SHIMANO COMPONENTS
IN TH E FR AME
Installation of power assist system components
requires advanced knowledge and may be be-
yond the skill of most users. Always go to an
lation of the components of the Rise electrical
system. Damage to components resulting from
incorrect installation could void the warranty on
those components.
See the following section for installation and con-
nection options for components on the stem and
handlebars.
1200mm
EW-SD300
to cockpit
Di2 transmission option
TECHNICAL MANUAL
-
900mm
EW-SD300
EW-SS301
760mm
BLUE PAPER RISE CARBON · 20 2 3
T10
0.6 N.m
SEE CENTERLOCK
ROTOR COMPATIBILITY
20
Di2 RD-M8150 option
ORBEA | 89
19
6-BOLT
Magnet
3
2.5 N.m
900mm
EW-SD300
SEE THE LIST OF COMPONENTS AT THE
END OF THIS SECTION
