54 | ORBEA
DISPLAY SC-EN600 (ON SELECTED MODELS)
FUNCTIONS
https://bike.shimano.com/en-EU/product/component/ep6-ep600/SC-EN600.html
CONNECTIVITY
ASSEMBLY
STEPS/DI2 CABLE STANDARD
MANUFACTURER'S MANUAL
SPEED SENSOR EW-SS301
ASSEMBLY
MAGNET
STEPS/DI2 CABLE STANDARD
TECHNICAL SPECIFICATIONS.
ORBEA EBIKE SYSTEM GEN2
ORBEA RS 540WH INTERNAL BATTERY. GEN2
VOLTAGE
CAPACITY
WEIGHT
CELLS
CHARGING TIME TO 100% (4A)
With RS Smart Charger Gen2
CHARGING TIME TO 80% (4A)
With RS Smart Charger Gen2
ASSEMBLY
CONNECTION
SEALING
CERTIFICATIONS
Compatible with Orbea Ebike System Gen2 systems on Orbea models
COMPATIBILITY
TECHNICAL MANUAL
See manufacturer's information:
On handlebar (35 mm clamp)
EW-SD300
On left chainstay. Internal wiring
On brake disc
EW-SD300
36 V
540 Wh
4.5 hours
3 hours
Internal. In downtube. Not user removable.
Cable harness to motor and charging port
ISO13849 > ISO13849-1:2015
UN 38.3
BLUE PAPER RISE CARBON · 20 2 3
ORBEA RS 360WH INTERNAL BATTERY. GEN2
VOLTAGE
CAPACITY
WEIGHT
CELLS
CHARGING TIME TO 100% (4A)
With RS Smart Charger
CHARGING TIME TO 80% (4A)
With RS Smart Charger
ASSEMBLY
CONNECTION
SEALING
CERTIFICATIONS
COMPATIBILITY
EXTERNAL BATTERY RANGE EXTENDER RS 252WH GEN2
VOLTAGE
CAPACITY
WEIGHT
CELLS
CHARGING TIME TO 100% (2A)
With RS Smart Charger
ASSEMBLY
CONNECTION Range Extender cable Gen1/2 to Rise Carbon charging port. 225 mm
SEALING
CERTIFICATIONS
Compatible with Orbea Ebike System Gen2 systems on Orbea models
COMPATIBILITY
ORBEA | 55
36 V
360 Wh
Approx 1.95 Kg
3.1 hours
2 hours
Internal. In downtube. Not user removable.
Cable harness to motor and charging port
ISO13849 > ISO13849-1:2015
UN 38.3
36 V
252 Wh
Approx 1.5 Kg
Lithium ion. Samsung 18650
3.5 hours
ISO13849 > ISO13849-1:2015
UN 38.3
