COMPONENTS REFERENCE
540WH 36V RS GEN 1
XA81
INTERNAL BATTERY
RANGE EXTENDER 252WH
Y041
RS GEN 1
CHARGING PORT + CABLE
XA84
HARNESS RS GEN 1
RS GEN 1 FRAME ON/OFF
XA85
BUTTON
RS GEN 1 - GEN 2 RANGE
XA86
EXTENDER CONNECTION CABLE
SMART CHARGER 4A-2A 42V
XA82
RS GEN 1
the Gen2 Smart Charger may cause a gradual self-discharge of the RE if it remains connected after reaching a full
charge. We always recommend using components of the same generation.
TECHNICAL MANUAL
RISE CARBON RISE HYDRO
LABEL
2021/22 2022
BLUE PAPER RISE CARBON · 20 2 3
KEMEN URRUN RISE CARBON
2022 2022 2023
mend using components of the same generation.
RISE HYDRO KEMEN
2023 2023
* * *
ORBEA | 125
