MAXIM UM AND MI N I MU M SA DDLE
HEIGHT WITH DROPPER SEATPOSTS
The following table gives the maximum and minimum
saddle heights with the dropper seatpost in the extended
position for each frame size.
Maximum saddle height refers to the height of the saddle
with the seatpost installed at its minimum insertion, de-
Minimum height refers to the height of the saddle with
by the frame.
Maximum and minimum heights are only given for the
dropper seatpost and saddle options assembled by Orbea
different dropper seatpost, see the seatpost manufactur-
of this manual.
MAX
TECHNICAL MANUAL
The dimensions on the following table de-
bottom bracket shell and the middle of the
upper part of the saddle (saddle models as-
sembled by Orbea).
Different saddles on the market can change
the dimensions given by +/-5 mm depending
on the height of the saddle model. If your
saddle height differs from a given dimension
by less than 5 mm, it is possible to adjust this
height by installing a different commercially
available saddle model.
If your saddle height differs from the given
dimensions by more than 5 mm, you should
-
choose a longer or shorter travel dropper
seatpost.
MIN
BLUE PAPER RISE CARBON · 2023
DROPPER SADDLE HEIGHT
SEATPOST EXTENDED
Minimum saddle height.
OC DP-MC20
Extended
31.6
Maximum saddle height.
125mm
Extended
Minimum saddle height.
OC DP-MC20
Extended
31.6
Maximum saddle height.
150mm
Extended
Minimum saddle height.
OC DP-MC20
Extended
31.6
Maximum saddle height.
170mm
Extended
Minimum saddle height.
OC DP-MC20
Extended
31.6
Maximum saddle height.
200mm
Extended
Minimum saddle height.
Fox Transfer
Extended
31.6
Maximum saddle height.
125mm
Extended
Minimum saddle height.
Fox Transfer
Extended
31.6
Maximum saddle height.
150mm
Extended
Minimum saddle height.
Fox Transfer
Extended
31.6
Maximum saddle height.
175mm
Extended
Minimum saddle height.
Fox Transfer
Extended
31.6
Maximum saddle height.
200mm
Extended
* The measurements may vary +/-5mm depending on the height of the saddle model.
