100 | ORBEA
25 ATTACH ME NT OF T HE E P 8 01 RS MOTO R
Inside.
Inside.
45.3
45.4
45.6
6
45.1
12 N.m
6 45.2
12 N.m
Always follow the recommended
torque settings.
45 RI S E C B 2 3 AT TAC H M E N T KI T F O R M OTO R EP 8 0 1 R S
ART No.: X568
45.1
45.2
45.3 Front motor spacer 8x22x12
45.4 O-ring seal 10x1
45.5 Washer 8x13x0.5
45.6 Washer 8.5x16.5x0.5
TECHNICAL MANUAL
6
45.1
12 N.m
45.6
45.4
6
45.2
45.3
12 N.m
45.5
6
45.2
12 N.m
45.5
45.5
45.5
45.2 6
12 N.m
QUANT.
2
4
2
2
4
2
BLUE PAPER RISE CARBON · 20 2 3
26 RS 540 WH /36 0WH G E N2 I NT E R NA L BAT T E R I E S
Refer to the RS battery maintenance, usage,
charging and storage recommendations in
the sections of this manual entitled "Main-
tenance" and "Warnings on the Use of the
Electrical Assist System" of this manual.
See also the process for charging, switching
on and checking the level of the batteries in
the "Using Rise" section of this manual. See
the section "Relevant information about RS
batteries" for more useful information about
use, care and problem solving for the internal
battery and Range Extender.
TECHNICAL SPECIFICATIONS OF THE RS 540WH GEN2 INTERNAL BATTERY
VOLTAGE
CAPACITY
WEIGHT
CELLS
CHARGING TIME TO 100% (4A)
With RS Smart Charger Gen2
CHARGING TIME TO 80% (4A)
With RS Smart Charger Gen2
ASSEMBLY
CONNECTION
SEALING
CERTIFICATIONS
COMPATIBILITY
COMPATIBILITY NOTICE. GEN2
ELECTRICAL SYSTEM COMPONENTS
The Orbea electrical system components
(internal battery -540Wh or 360Wh-, Range
Extender, cable harness and Smart Charger)
Rise, Kemen or Urrun models from ranges
prior to 2023 with Orbea Gen0 and Gen1
electrical system components.
These Orbea Ebike Systems components
from the 2023 range are designed to guar-
See the Orbea Ebike Systems Compatibility
Orbea components with our different bicycle
models.
36 V
540 Wh
4.5 hours
3 hours
Internal. In downtube. Not user removable.
Cable harness to motor and charging port
ISO13849 > ISO13849-1:2015
UN 38.3
Compatible with Orbea Ebike System Gen2 systems in
ORBEA | 101
