RS 2A-4A GEN2 SMART CHARGER
INPUT
OUTPUT
INTERNAL BATTERY CHARGING CURRENT
RS 540Wh
RANGE EXTENDER RS 252Wh CHARGING
CURRENT The Smart Charger RS recognises which battery is connected and adapts
CHARGING TEMPERATURE RANGE
CHARGE DISPLAY
CERTIFICATIONS
COMPATIBILITY
ORBEA RS WIRING. GEN2
CABLE HARNESS RS Gen2. Internal
battery-motor-charging point connection
Compatible with Orbea Ebike System Gen2 systems on Orbea models with
COMPATIBILITY
TECHNICAL MANUAL
100-240V. 50-60Hz. AC
42V 4A DC
4A
2A
the charging current
Charging process and errors display LED
CE: EN60335-1, EN60335-2-29
RCM, SAA: AS/NZS 60335.2.29
CE: UKCA: EN55014-1/2, EN610003-3/2
motor from the 2023 range onwards
Communication protocol:
Sealing:
BLUE PAPER RISE CARBON · 20 2 3
COMPONENTS. EXPLODED VIEWS, ASSEMBLY, USE
AND SPARE PARTS

1 1 HS02 HEADSET

HEAD TUBE DIMENSIONS
HS02 HEADSET SPECIFICATIONS
Headset
TYPE ID* OD**
race angle
TOP 52,1mm 58mm
BOTTOM 52,1mm 58mm
* ID: Headset tube internal diameter. ** OD: Headset tube outer diameter.
ø58
ø52.1
Preload ring / fork crown SHIS Bearing code
race contact angle CODE Enduro dimensions
Angular contact
IS52/40
Angular contact
IS52/40
