SPINBLOCK FUNCTION. HEADSET
STE ERIN G L IMITE R
The Rise Carbon headset has a Spinblock function, which
sary manoeuvrability, but preventing the handlebar and its
components from hitting the frame in the event of a fall.
164º
For the Spinblock function to work correct-
ly, all components of the headset, including
the stem, must be Spinblock compatible.
The frame cover, the steering spacers, the
SIC collector and the stem must have the
sure that the headset rotation limit is trans-
mitted to the stem.
TECHNICAL MANUAL
- the rear part of the head tube and a rotation channel in the
headset spacers below the stem. They are
not designed for this use and may be dam-
aged. If these spacers are installed below
the stem, the Spinblock function may be af-
fected and damage to the frame may occur
- in the event of a fall if the Spinblock does
not work correctly. Damage to materials
resulting from the incorrect installation of
components is not covered by the warranty
conditions.
BLUE PAPER RISE CARBON · 20 2 3
USIN G STEM S W ITH NO SPINBLOC K
FUNCTION
with the use of round headset spacers can be used on Rise
the universal SIC collector (10.1).
SEE THE LIST OF COMPONENTS AT THE END OF
THIS SECTION
No Spinlock function with Universal
Collector and regular stems
ORBEA | 63
E N
Standard non
OC stem
See cabling
7
section
10
5.2
5.1
4
The use of standard stems that are not com-
patible with the Spinblock function will cause
the headset rotation limit to be lost, since the
rotation limit cannot be transmitted to the
stem since the universal collector and the
stem do not have the necessary mounting
non-OC stems that require the use of the uni-
versal SIC collector.
Orbea does not guarantee the compatibil-
assemblies. Check that the stem measure-
ments to be used allow a correct assembly
of all the components and that they allow the
entry of the cables and housings through the
SIC collector.
