130 | ORBEA
ORBEA RS GEN2 BATTERIES IN ETUBE
PROFESSIONAL
The Orbea RS Gen2 battery is visible as part of the Shimano
version and charging cycles, under the Maintenance tab.
TECHNICAL MANUAL
Orbea RS Gen2 internal batteries cannot be
a problem with the Rise electrical system, use
-
is not in another Shimano component of the
electrical system.
Contact Shimano to provide a system report
through a claim. If Shimano informs you that
the problem is related to the internal battery,
contact Orbea via a claim.
BLUE PAPER RISE CARBON · 2023
CO NN ECTING LIGH TS TO TH E SHIM A NO
EP8 0 1 RS MOTOR
Rise is not designed for the use of lights
connected to the motor, so the user and/or
Shimano dealer who wishes to perform this in-
stallation is responsible for it if it is carried out.
IMPORTANT: Using lights connected to
the EP801 motor can considerably re-
duce your bicycle's range.
to the ports provided on the motor itself (bare wire).
Rise is delivered with the motor light ports disabled.
However, an authorised Shimano dealer can enable the
It is possible to choose whether the lights will always be
on when the bike is switched on or whether the user can
choose to switch them on via the display.
ORBEA | 131
IMPORTANT: See the wiring section of this
manual for options related to SIC seals of
the HS02 headset collector and options
related to the front light cable outlet,
should you wish to install it. Orbea's Rise
assemblies do not have lights. Orbea is
not responsible for the compatibility of
aftermarket assemblies installed by users
or a dealer. Make sure that components
are compatible before installing them.
IMPORTANT: There are laws that could require an
ebike with lights to automatically set aside a percent-
age of the battery charge to power the lights for a set
amount of time when the battery is running low by
switching off the motor assist. Always follow the reg-
ulations of the territory where you use your bicycle.
