58 | ORBEA
HEADSET EXPLODED
VIEW AND ASSEMBLY
BEARINGS AND SIC ADAPTER
2
1.1
3
1.1
1.2
Starnut
Fork´s steerer tube
TECHNICAL MANUAL
GREASE
SEE THE LIST OF COMPONENTS
AT THE END OF THIS SECTION
BLUE PAPER RISE CARBON · 20 2 3
"REGULAR STACK" AND "LOW STACK"
HEADSET ASSEMBLIES (OPTIONAL)
The HS02 headset allows for two different assemblies
ferred stem and handlebar height.
REGULAR STACK
(4) and SIC cabling collector (6).
The headset spacers to be used below the stem (5.1, 5.2)
are mounted between the frame cover and the collector to
achieve the desired stem height.
The headset spacers to be used on top of the stem (8.1,
LOW STACK
tor that acts as a frame cover (9).
This collector is not compatible with the use of steering
spacers below the stem (5.1, 5.2) .
The headset spacers to be used on top of the stem (8.1,
-
sets are only compatible with the use of
OC stems compatible with the Spinblock
function (see the Spinblock section in this
-
chapter).
-
ORBEA | 59
