2 9 RELEVANT INFORMATION ON ORBEA RS
LITHIUM-ION BATTERIES
For your safety, read the entire User Man-
ual before using Orbea RS batteries and
chargers.
Contact Orbea or an authorised dealer
for information on installing and adjusting
products not found in the User Manual.
The instructions below must be followed at
all times to avoid injury or damaging the
equipment and the environment.
The information in the following manual
applies to both the internal battery and the
Range Extender.
COMPATIBILITY NOTICE. GEN2 ELECTRICAL SYSTEM
COMPONENTS
The Orbea components of the electrical system (internal
battery -540Wh or 360Wh-, Range Extender, cable harness
and Smart Charger) are not compatible with Rise, Kemen
or Urrun models from ranges prior to 2023. These Orbea
Ebike Systems components from the 2023 range are de-
the internal batteries (540Wh or 360Wh), the Range Ex-
tender and the Smart Charger are marked with the Gen2
mark to identify their compatibility with these systems.

BATTERY SAFETY INSTRUCTIONS

AND WARNINGS
tery. Failure to do so may result in overheating, explo-
sion or ignition of the battery.
· Do not leave the battery near heat sources such as
heaters, vehicles or any hazardous location.
· Do not deform, modify or disassemble the battery or
apply solder directly to it.
TECHNICAL MANUAL
· Do not connect the (+) and (-) terminals and other ter-
minals with metal objects. Do not carry or store the
battery with metal objects such as necklaces or hair-
pins. This can cause short circuits, overheating, burns
or other injuries.
· Do not immerse the battery in water and do not allow
the battery terminals to get wet. Failure to do so may re-
sult in overheating, explosion or ignition of the battery.
· Do not puncture or crush the battery.
with the eyes, skin or clothing, immediately rinse the
affected areas with abundant fresh water and seek
age your eyes and skin.
· If the battery is not fully charged within the designat-
ed charging time of 5 hours plus an additional 2 hours
(3.5 hours + 2 hours for the Range Extender), unplug
the battery from the charger and contact an authorised
dealer immediately.
· Do not use the battery if it has any external damage.
· Do not use the battery if it is leaking, discoloured, de-
formed or if it has any other anomaly.
· Do not charge the battery in wet or very humid places
or outdoors.
· Do not plug in or unplug the battery if it is wet. Doing so
can cause an electric shock. If water comes out of the
socket, dry it thoroughly before plugging it in.
-
· Do not store the battery in direct sunlight or in excessive-
ly hot places (such as inside a car). Keep it away from
· Use both hands when handling the product to avoid
hazards and injuries.
· If an error occurs during discharging or charging, stop
using the battery immediately and refer to the User
Manual. If you are unsure, please consult Orbea or an
authorised dealer.
BLUE PAPER RISE CARBON · 20 2 3
· Do not clean the battery with high pressure water.
· Do not use alcohol, solvents or abrasive cleaners to
clean the battery or charger. Use a dry or slightly damp
cloth.
· Children should be supervised to ensure that they do
not play with the battery and charger.
diately and carefully remove other batteries if possible.
ately and use plenty of cold water (at least 10 times the
BATTERY STORAGE CONDITIONS
-
· Store batteries in a safe place out of reach of babies
and pets.
· Storing the battery at temperatures outside this range
· Storage temperature range: 0°C ~35°C. Avoid
large changes in temperature. Humidity: 5%-65%.
· If you are not going to use it for a long period of time,
damaging the battery.
not exposed to direct sunlight or rain. Low or high
storage temperatures reduce the battery's perfor-
mance and the range per charge may decrease as a
result. After not using the battery for a period of time,
be sure to charge it before use.
hazard.
BATTERY USAGE CONDITIONS
· The battery operating temperature ranges are listed
below. Do not use the battery in temperatures outside
these ranges.
· Using the battery at temperatures outside these ranges
· Only use the battery within the discharge tempera-
ture range: –10 ° C ~ 40 ° C.
· Only charge the battery within the charging tem-
perature range: 0 ° C ~ 40 ° C.
- · The battery should be charged at room temperature,
-
· If the battery has been charged in a low temperature
per full charge.
· If you wish to transport the battery, please note that it
is considered as hazardous goods under current regula-
tions. Use approved packaging and carriers.
BATTERY ASSEMBLY CONDITIONS
· Do not use the battery immediately after receiving the
battery or the bicycle. Make sure that it is fully charged
- · Always switch off the battery and/or the bicycle before
inserting or removing the battery from the bicycle.
CHARGING CONDITIONS AND SAFETY
INST RUCTIONS
· The battery is not fully charged at the time of purchase.
· Use only the original RS charger to charge the battery.
· Always switch off the bicycle and/or the battery before
connecting or disconnecting the charger to the charg-
ing port.
· Make sure the bicycle's charging port and plugs are al-
ways clean and dry before connecting the charger.
