18 | ORBEA
· Always connect the cables the right way round. Connect-
ing the cables without making sure they are the right
way round can damage the terminals.
properly closed to prevent dirt and water from getting
into the charging port.
Do not use metal tools to clean the charging port of any
dirt or foreign body. Do not damage the charging port
terminals during this process.
See the section "Relevant information about
RS batteries" for more useful information
about use, care and problem solving for the
internal battery and Range Extender.
and its components:
User manual:
Dealer manual:
https://si.shimano.com/es/dm/DUE001
RA NGE
bea RS batteries, have been designed to provide the max-
imum range available for a system of its reduced weight
and small size.
ECO
360Wh battery
540Wh battery 3500m
Range Extender 252Wh +1400m
TECHNICAL MANUAL
The available range per charge depends strongly on vari-
ous factors such as:
· Assist mode: Using higher assist levels will decrease
the available range.
·
power of each assist mode, so range may be affected.
· Customisation of assist modes: Approximate range
values take into account the power values of each assist
mode, according to Orbea's original settings. Custom-
ising the power delivery of each mode via the Shimano
· Temperature: Charging and using the battery at a low
temperature will decrease the range per charge.
· Weight of the cyclist and gear/luggage.
· How hard the cyclist pedals.
· Terrain and slopes: Use on broken ground and uphill
will affect the range available per charge.
· Frequent stops and starts can affect the available range.
APPROXIMATE CUMULATIVE ELEVATION GAIN TABLE:
-
Take into account all the factors described in the previous
TRAIL BOOST
1900m 1250m
2500m 1600m
+1000m
BLUE PAPER RISE CARBON · 2023
TRA N SPORTING TH E BATTER IES
OF ELECTRIC BICYCLES
The Orbea RS internal battery and the Range Extender ex-
ternal battery must be transported in compliance with the
regulations in force by the means of transport permitted
for these articles. The units must always be transported or
shipped using the original approved packaging and an ap-
proved carrier. Find out about the handling and transport
conditions of this type of item in your country.
If the Range Extender or internal battery have to be sent to
Orbea for repair or diagnosis, it must be sent in its original
must be used. Orbea can provide information about your
best option.
If you need the safety documentation for the RS batteries
(MSDS) for transport, or the shipping company requests
this documentation, contact Orbea and we will provide it.
TRA N SPORTING ELECTRIC
BICYCLES
about the battery transportation conditions of the airline
you plan to use to transport your bicycle. Most commer-
cial airlines do not allow the transport of batteries with a
capacity greater than 100 Wh.
If you need the safety documentation for the RS batteries
(MSDS) for transport, or the shipping company requests
this documentation, contact Orbea and we will provide it.
ORBEA | 19
