Oc St-Mc10 / St-Mc20 Stems - Orbea Blue Paper Rise Carbon 2023 Manual Tecnico

80 | ORBEA
OC ST-MC10 / ST-M C 2 0 ST EM S
OC RANGE
MATERIAL
Ø FORK
Ø HANDLEBAR (C)
MOUNTING HEIGHT IN FORK TUBE
ANGLE (B)
AVAILABLE LENGTHS (A)
CABLING
SPINBLOCK FUNCTION
SIC COMPATIBLE
COMPATIBLE HEADSET STANDARD
WEIGHT
STEM COVER
STEM TOP SPACERS
STEM BOTTOM SPACERS
COMPUTER MOUNT (Optional)
TECHNICAL MANUAL
A
C
Mountain Control
CNC Aluminium
35 mm
40 mm
35 mm - 40 mm - 50 mm
Compatible with internal mechanical cabling: No
Compatible with internal electrical wiring: Yes
Yes
Yes
Orbea HS02
ST-MC10: 150g (40mm)
ST-MC20: 160g (40mm)
HS02-31 Topcap. ST-MC10/20
HS02-04/03 10/5 mm split headset spacer
OC CM-05 MC HS02. On stem. 5 mm ISS02 interface
BLUE PAPER RISE CARBON · 20 2 3
3 9 O C ST E M ST- MC 1 0
ART No.: C025
39.1 OC ST-MC10 Stem
(35 mm - 40 mm - 50 mm)
39.2 OC ST-MC10 stem faceplate
39.3 M5x15 R8 Tapered bolt. CrMo
39.4 Steerer clamp limit ST-MC10-11.
39.5 HS02-31 Topcap. ST-MC10/20
39.6
41 TOPCAP ST-MC10/20. HS02-3 1
ART No.: XC79
41.1 HS02-31 Topcap. ST-MC10/20
41.2
METHOD FOR FIXING THE FACEPLATE
OF THE STEM ON "NO GAP" MTB STEMS
and stem body make contact. Then tighten the set screws
Check the tightening torque of the 4 faceplate screws in a
cross pattern.
1
4
No Gap
4
2
6 N.m
4 0 OC ST EM ST- M C 20
QUAN T. ART No.: C026
40.1 OC ST-MC20 Stem
1
(35 mm - 40 mm - 50 mm)
1 40.2 OC ST-MC20 stem faceplate
6
40.3 M5x15 R8 Tapered bolt. CrMo
40.4 Steerer clamp limit ST-MC10-11.
1
1 40.5 HS02-31 Topcap. ST-MC10/20
1 40.6
4 2 O C ST EM B OLT KI T
Q UAN T. ART No.: XC78
1 42 M5x15 R8 Tapered bolt. CrMo
1
Compatible with all OC stems except
1 3
4 2
ORBEA | 81
E N
QUAN T.
1
1
6
1
1
1
QUAN T.
6
4
6 N.m
