68 | ORBEA

LINKAGE EXPLODED VIEW

25
24
24
25
23.2
20
20
23.2
23.1
26
23.1
23.2
20
20
23.2
18.2
22
18.5/19.3
21
21
22
18.1
TECHNICAL MANUAL BLUE PAPER RISE CARBON · 2023
18 RISE CB 23 LINKAGE
Bearings not included
ART No.: X978
18.3/19.1
18.4/18.2
20 RISE CB 23 LINKAGE BEARING KIT
ART No.: XA24
22 LINKAGE AXLE-RISE FRAME CB 23 SEALING RINGS KIT
ART No.: X980
24 LINKAGE-RISE CB 23 SHOCK YOKE HARDWARE KIT
Bearings not included
ART No.: X982
26 OC MT-20 FLP LINKAGE AXLE MULTITOOL
ART No.: C064
1 9
QUA NT. ART No.: X979
18.1 Right linkage+axle assembly 1
18.2 Left linkage 1
18.3 Right linkage pre-load bolt. With magnet 1
18.4 1
18.5 Right linkage attachment bolt M6x16
1
DIN912
2 1
QUAN T. ART No.: XA25
Enduro Max 6800 10x19x5 bearing 4
23
QUAN T. ART No.: X981
Acros sealing ring 20x32 2
2 5
QUAN T. ART No.: X983
Shock-linkage extension bolt 2
QUAN T.
1
ORBEA | 69
LINKAGE RISE CB 23 HARDWARE KIT
Bearings not included
QUA N T.
19.1 Right linkage pre-load bolt With magnet
19.2
19.3 Right linkage attachment bolt M6x16
DIN912
LINKAGE-FRAME AXLE BEARINGS KIT
QUA N T.
RISE CB 23 LINKAGE-SEATSTAY HARDWARE KIT
Bearings not included
QUA NT.
23.1
23.2 Linkage-seatstay bolt spacer 10x14x2
RISE CB 23 SHOCK YOKE BEARINGS KIT
QUA N T.
EN
1
1
1
2
2
4
2
