2 1 CABLING OF MECHANICAL COMPONENTS

C A B L I N G I N T HE F R A ME O F D E R A I L L E U R , R E A R B R A K E
A ND D R O P P E R S E AT P O S T R E M O T E
37.2 2
2 N.m
37.1
Secure the hose around the end
with the included cable tie to prevent
friction against the spokes
37 CHAINSTAY BRAKE CABLE GUIDE+CABLE TIE
ART No.: X988
Chainstay brake cable guide
TECHNICAL MANUAL
Cables above the
battery.
Not crossing
L
R
(All frame sizes):
L = 135 mm
R = 145 mm
3 8 RISE TRIANGLE-SWINGARM HOSE KIT
QUAN T. ART No.: X220
1 38.1 FS Hose (Single size)
1 38.2 FS hose sensor clip (Single size)
1 38.3 FS hose end
BLUE PAPER RISE CARBON · 20 2 3
C A B L I N G T H R O U G H S I C H S 0 2
HE A DSE T
38
Rear derailleur
For left rear brake setups,
the hose enters the headset
through the right grommet
Q UANT.
1
1
2
Rear brake
For left rear brake setups,
the hose enters the headset
through the right grommet
Rear derailleur
Dropper seatpost
Rear brake
ORBEA | 77
E N
Dropper seatpost
