FRAME CABLE ROUTING
OF SHIMANO COMPONENTS
The installation and replacement of the electric
system components requires an advanced techni-
cal knowledge and may therefore be beyong the
Always take your bicycle to an authorized dealer
for the diagnosis, repair and installation of the
Damage to the components derived from incor-
rect installation may void the warranty on such
TECHNICAL MANUAL
Option 1: Shimano SC-EM800 display
SW-EM800-L
SC-EM800 7
9
3
2
Option 2: Shimano EW-EN100 juntion (no display)
SW-EM7000 L
10
EW-EN100
6
4
EW-AD305
5
2
Option 3: Shimano SC-E7000 display
SW-E7000 L
SC-E7000 8
10
4
5 EW-AD305
2
B LUE PAP ER R I SE · HYDRO 2022
2
ORBEA | 73
E N
T10
0.6 N.m
See Centerlock 6-BOLT
Rotor Compatibility
19
Magnet
3
2.5 N.m
11
CONSULT THE COMPONENTS LIST
AT THE END OF THIS SECTION
