74 | ORBEA
FRAME CABLE ROUTING
OF ORBEA RS COMPONENTS
The installation and replacement of the electric
system components requires an advanced tech-
nical knowledge and may therefore be beyong
Always take your bicycle to an authorized dealer
for the diagnosis, repair and installation of the
Damage to the components derived from incor-
rect installation may void the warranty on such
TECHNICAL MANUAL
The Orbea RS components used on Rise H
(internal battery, harness cable, On/Off bu-
tton, charger and Range Extender) are not
B LUE PAP ER R I SE · HYDRO 2022
15
Battery
14
Motor
15
Inside frame
CONSULT THE COMPONENTS LIST
AT THE END OF THIS SECTION
ORBEA | 75
E N
16
On / Off
button
