26 | ORBEA
LED 2
X
OFF > ECO > TRAIL > BOOST
Y
BOOST > TRAIL > ECO > OFF

CHANGING THE ASSIST LEVEL

WITH THE SHIMANO SW-EN600-L SWITCH UNIT
To change the assist mode to pedalling with the SW-
EN600L lever, press the X button to increase the assist
without electrical assist.
The available assist modes are:
· OFF (no electrical assist)
· ECO
· TRAIL
· BOOST
When the assist mode is changed, the LED2 on the lever
will change colour to show the current assist level. In as-
semblies with a display, the name of the current level will
be shown on the display.
WALK ASSIST
To activate the Rise walk assist mode, press and hold the
Y button on the SW-EN600L switch unit for 1 second until
the word "WALK" appears on the display or the LED 2
lights up blue on the remote control.
Release the Y button on the remote control and press it
again to activate the walk assist. The system will keep the
TECHNICAL MANUAL
SC-EN600 DISPLAY
BOOST
TRAIL
ECO
No assist
walk assist activated as long as you keep pressing the Y
button on the remote. While the walk assist is activated,
the WALK mode, press the X button on the remote control.
The manual for the SW-EN600-L switch unit can be
found here:
https://si.shimano.com/es/manual/search?mod-
el=SW-EN600-L
The manual for the Shimano SC-EN600 display can be
found here:
https://si.shimano.com/es/manual/search?input_mod-
el=sc-en600
SC-EN600 DISPLAY
WALK
Release
Y
1 SEC
&Hold
LED 2 LED 2
BLUE PAPER RISE CARBON · 20 2 3
C USTOMISIN G THE PROFIL ES
AND ASSIST LEVELS
the Shimano Etube mobile app for a more customised ex-
perience.
electrical assist levels can be independently customised

BASIC MODE

· BASIC:
assist and maximum torque characteristics of each level
LED 2
X
OFF > ECO > TRAIL > BOOST
BOOST
TRAIL
ECO
No assist
Y
BOOST > TRAIL > ECO > OFF
ORBEA | 27
