OPERATING THE SIDERAILS

To raise the siderails, as shown in Figure 29, lift up on the siderail until the latch clicks and the siderail locks into place .
To lower the siderails, squeeze handle (B) to release the siderail latch . Guide the siderail down toward the foot end
until flat . Ensure that the siderails are lowered when a patient is being transferred to or from the cot .
WARNING
Siderails are not intended to serve as a patient restraint device . See page 1-36 proper restraint strap usage . Failure to
use the siderails properly could result in patient injury .
A
B
Head End
Figure 29: Backrest Elevated and Siderails Raised
OPERATING THE BACKREST
To raise the backrest, as shown in Figure 29, squeeze handle (A) for pneumatic assist in lifting the backrest to the
desired height .
To lower the backrest, squeeze handle (A) and push down on the backrest frame until the backrest has reached the
desired height .
