English
ADJUSTING THE HEIGHT OF AN EMPTY COT WITH ONE OPERATOR
To raise or lower the cot from the foot end:
1 . Standing at the foot end of the cot, grasp the lower foot end lift tube .
2 . Tip the cot up onto the load wheels (see Figure 14) .
3 . Squeeze and hold the release handle and raise or lower the foot end to the desired position . The handle is
released when the desired position is reached .
4 . Lower the cot back onto the four base wheels (see Figure 15) .
Figure 14: Cot Tipped on Load Wheels
To raise or lower the cot from the side:
1 . Place one foot on the outer base tube .
2 . Grasp the side release handle with one hand . Place your other hand on the outer support rail to help stabilize the
cot (see Figure 16) .
3 . Squeeze the side release handle and raise or lower the cot to the desired position . The handle is released when
the desired position is reached (see Figure 17) .
WARNING
If lowering the cot to the lowest position (position 1), remove your foot from the base tube or injury could result .
Figure 16: Holding Outer Support Rail
Return To Table of Contents
1-24
Cot Operation
Figure 15: Cot Lowered to Ground
Figure 17: Lowering Cot from Side
6086-009-005 REV A www.stryker.com
