Before placing the cot into service, confirm that the cot load height is set correctly for your vehicle . The cot load height
can be adjusted to match the height of the vehicle deck . If the cot does not line up correctly, adjustments may need
to be made to the cot load height .
WARNING
Before placing the cot into service, confirm that the cot load height is set correctly for your vehicle .
To check the load height of the Performance-PRO™ XT cot:
1 . Roll the cot up to the loading area of your vehicle .
2 . Compare the difference between the deck height of the
vehicle and the load height of the cot .
3 . Select HIGH, MID or LOW depending on the cot load
height requirements (see Figure 12) . For example:
• The HIGH marking on the rack is recommended for
vehicle deck heights above 32 inches .
• The MID marking on the rack is recommended for
vehicle deck heights between 30 and 32 inches .
• The LOW marking on the rack is recommended for
vehicle deck heights below 30 inches .
4 . Verify that the safety hook always engages the cot safety
bar, regardless of how the cot is unloaded from the
vehicle . If the safety bar misses the safety hook, select
the next lower height setting .
www.stryker.com
Adjusting Cot Load Height
6086-009-005 REV A
Figure 12: Cot Load Height
