English
Note: These installation instructions are intended for cots that you will NOT use with Power-LOAD . For Model 6086
cots with the Power-LOAD option, see the Power-LOAD Operations/Maintenance Manual (6390-009-001) for installation
instructions .
RAIL SUPPORT BRACKET
14 5/8" (REF .)
(37,1 cm)
OR DESIRED
POSITION FROM
WALL
REAR OF
AMBULANCE
(REF .)
14 5/8"
(37,1 cm)
REAR OF
AMBULANCE
(REF .)
Return To Table of Contents
1-14
Cot Fastener Installation
FLOOR PLATE
12 5/8" (32 cm)
2 5/8"
(6,6 cm)
Figure 4: Installation Specifications - Floor Mount Fastener
3 5/8"
(9,2 cm)
(16,5 cm)
6 1/2"
4 5/16"
(10,9 cm)
Figure 5: Installation Specifications - Wall Mount Fastener
WALL OF VEHICLE
COT CENTER LINE
COT PERIMETER
37 5/8"
(95,6 cm)
80" (REF .)
(203 cm)
WALL OF VEHICLE
COT CENTER LINE
COT PERIMETER
80" (REF .)
(203 cm)
37 3/8"
(94,9 cm)
WALL MOUNTING BRACKET
FLOOR OF
VEHICLE
6086-009-005 REV A
ANTLER FLOOR
PLATES
COT
HEAD
END
24"
(REF .)
(61 cm)
14 15/16"
6 1/8"
(37,9 cm) (15,6 cm)
ANTLER FLOOR PLATES
COT
24" (REF .)
HEAD
(61 cm)
END
1 1/8"
(2,9 cm)
14 15/16" 6 1/8"
(37,9 cm) (15,6 cm)
