INSTALLING THE HEAD END STORAGE FLAT

WARNING
When the optional head end storage flat is being used, ensure that it does not interfere with the operation of the
retractable head section, safety bar and safety hook . Injury to the patient or operator could result .
B
Cross Bar
To install the optional head end storage flat (see Figure 60):
1 . Install the Velcro ® straps (A) near the pneumatic cylinder and around the cross bar of the retractable head section .
2 . Buckle the restraint straps (B) around the outer rails of the retractable head section .
CAUTION
• Do not store items under the cot mattress . Storing items under the mattress can interfere with the operation of
the cot .
• The weight of the equipment in the head end storage flat (if equipped) must not exceed 40 lb (18 kg) .

USING THE TRANSFER FLAT

When transferring larger patients, use of the Transfer Flat (6005-001-001) is recommended .
www.stryker.com
Optional Accessories
A
A
Figure 60: Head End Storage Flat
6086-009-005 REV A
B
V-Tube
