STEP 10: Install the kickstand
a. Loosen screws and washers and then remove them from the dropout,
as shown in Figure 10-1.
b. Use a 5 mm Allen key to mount the kickstand onto the dropout, and
retighten the screws to the torque of 10-12 N·m.
Pumping a bicycle tire
To pump your tires, you will need:
Bicycle pump with Presta valve compatibility
or
Presta valve adapter (if your pump does not have a built-in Presta valve
head) not included.
How to pump a tire
a. If your pump has a dual head (fits both Presta and Schrader valves),
make sure it's set up for Presta valves. If your pump is not Presta-
compatible, you'll need a Presta valve adapter. Attach the adapter to
the pump head.
b. On the bicycle, unscrew the small nut at the top of the Presta valve by
turning it anti-clockwise. This allows the valve to open and allows air to
flow into the tire.
c. Press down on the Presta valve to release a small amount of air. This
helps ensure that the valve is not stuck and allows the pump to engage
properly.
d. Press your pump onto the Presta valve as far as you can.
e. If your pump has a lever, flip it down to secure the pump head onto the
Presta valve. This creates an airtight seal.
f. Begin pumping air into the tire.
g. Once you've reached the desired tire pressure, disconnect the pump
head by releasing the lever or unscrewing it.
h. Screw the small nut at the top of the Presta valve clockwise to close it.
How to use the E-bike
Fully charge the battery before first use.
How to charge
a. Open the rubber cap and plug the charger into the e-bike charge port
Figure 11-1. Make sure that the charger port is in the given direction,
as shown in Figure 11-2.
b. Plug the charger into the mains wall socket.
c. When connected to the battery charger, the battery will start to charge
and the charge indicator on the charger will turn red.
d. After the charging is complete, the charge indicator will turn green.
Remove the battery charger when fully charged.
e. Close the rubber cap after charging.
7
Figure 10-1
Figure 11-1
How to start an E-bike
ON/OFF
Press and hold the power button ON/OFF for 3 seconds to turn on the
display.
PAS UP button
PAS DOWN button/
Press & hold 6 km/h push assistance button
Pedal Assist Level
The Motor offers five Bike Assists Models: ECO, NORMAL, TOUR, POWER,
BOOST. Short press Up or Down to switch the pedal assist level.
Bluetooth
device
connected
Display Interface
By default the display shows real-time speed (km/h), the single mileage
(km), and the Total mileage (km). Press the MODE button briefly to switch.
Figure 11-2
ON/OFF button
Mode button
Battery Indicator
Real Time speed
Toggle Riding Info
PAS level
