EN
Slide the top of the new charcoal filter into the
A5.4
top of the filter cavity.
Press the bottom of charcoal filter to place it
A5.5
into the correct position.
A5.6 Reinstall the vent by sliding the bottom of the vent
into place. Push the vent top into position and slide
right into place. Replace the two vent mounting
screws located on top of the microwave using a #1
Phillips screwdriver.
A5.7 Close the microwave door. Plug in microwave oven
or reconnect power.
IMPORTANT: Remove the cardhoard spacers between
heat shield and door.
INSTALLING OR CHANGE THE CARBON FILTER
A6.
(OTRFILTER1) (OPTIONAL)
A6.1 Remove the carbon filter (OTRFILTER1) from the
packaging and shake filter to remove excess carbon.
A6.2 Use a Phillips head screwdriver to unscrew the
carbon filter (OTRFILTER1) access door.
A6.3 Open the filter access door.
Remove the existing carbon filter (OTRFILTER1)
A6.4
(if installed) by pulling forward out from the unit.
Place the new carbon filter (OTRFILTER1) into the
A6.5
slot behind the door at an angle until it's upright
and securely placed in the duct.
11
