ENGLISH
Adding extra crockery
Without switching off the machine, open the door (START/Pause led
starts blinking) (be aware of HOT steam!) and place the crockery
inside the dishwasher. Press the START/Pause button and close the
door within 4 sec., the cycle will resume from the point at which it
was interrupted.
Functions
Functions can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an function is not compatible with the
selected program (see PROGRAMS TABLE), the corresponding LED flashes rapidly 3 times and beeps will sound. The function will
not be enabled.
FLEXIBLE WASH
If there are not many dishes to be washed, a half loading
may be used in order to save water, electricity and
detergent.
Select the program and then press the FLEXIBLE WASH
button: the symbol of the chosen rack will appear on the
display. By default the appliance washes dishes in all racks.
To wash only the specific rack, press this button repeatedly:
shown on the display (only lower rack)
shown on the display (only upper rack)
shown on the display (option is OFF and the appliance will
wash dishes in all racks).
DELAY
The start time of the program may be delayed for a period
of time between 1 and 12 hours.
1. Press the DELAY button: the corresponding «h» symbol
appears on the display; each time you press the button,
the time (1h, 2h, etc. up to max. 12h) from the start of
the selected wash cycle will be increased.
2. Select the wash program, press the START/PAUSE button
and within 4 seconds close the door: the timer will begin
counting down.
3. Once this time has elapsed, the indicator light «h»
switches off and the wash cycle begins.
To adjust the delay time and select a shorter period of
time, press the DELAY button. To cancel it, press the button
repeatedly until the selected delayed start indicator light
«h» switches off.
The DELAY function cannot be set once a wash cycle
has been started.
SHORT TIME
This option can be used to reduce the duration of
the main programs while maintaining the same
performance.
Select a program, press the SHORT TIME button and
the indicator light will switch on. To deselect the option,
press the same button again.
EXTRA DRY
A higher temperature during the final rinse as an
extended drying phase which allows improved drying.
After selecting the program, press the EXTRA DRY
button and the indicator light comes on.
To deselect the option, press the same button again.
The EXTRA DRY option results in the lengthening of the
wash cycle.
TABLET (Tab)
Press the START/PAUSE button for 3 seconds (the cor-
responding symbol will light up) if you use combined
detergents in tablet form (rinse aid, salt and detergent
in 1 dose).
If you use powder or liquid detergent, this function
should be off.
Accidental interruptions
If the door is opened during the wash cycle, or if there is a power cut,
the cycle pauses. Press the START/Pause button and close the door
within 4 sec., the cycle will resume from the point at which it was
interrupted.
OPERATION INDICATOR
A LED light projected on the floor indicates that the
dishwasher is working. One of the following operating
modes can be selected:
a) Disabled function.
b) When the cycle starts the light goes on for few
seconds, stays off during the cycle and flashes at the
end of the cycle.
c) The light stays on during the cycle and flashes at the
end of the cycle (default mode).
If the delayed start was set, the light goes on either
for the first few seconds or the entire duration of the
countdown, based on whether mode b) or c) was set.
The light goes off every time the door is opened. To select
the mode you prefer, switch on the machine, hold down
button until one of the three letters appears on the
display, press button
(or mode), hold down button
Note: If NaturalDry is active and it opens the door, then
Operation Indicator will not flash at the end of the cycle.
NATURALDRY
Door opening system - NaturalDry is a convection drying
system which automatically opens the door during/after drying
phase to ensure exceptional drying performance every day.
Door opens at the temperature that is safe to your kitchen
furniture. As additional steam protection, special designed
protection foil is added together with the dishwasher. To see
how to mount protection foil please refer to (ASSEMBLY
INSTRUCTION). NaturalDry functionality could be disabled by
the user as follows:
1. Go to the Operation Indicator menu as in last step, press and
hold until menu appeares.
2. Press and hold again for 6 seconds to reach the
NaturalDry menu.
3. You switched to NaturalDry Control Menu, you could change
status of NaturalDry functionality by pressing button
E – enabled d – disabled
To confirm the change and exit from the Control Menu
please press and hold button (3 sec).
Eco 50°
Auto 50°-60°
Intensive 65°
Fast Wash 30' 50°
Fast Wash and Dry 50°
Glass 45°
Silent 50°
Sanitizing 65°
Pre-Wash
Self-Clean 65°
* depending on settings
until you reach the desired letter
to confirm the selection.
:
DOOR OPENING
165 min
80-175 min*
165 min
end of cycle
80 min
95 min
205 min
N/A
N/A
N/A
