Stihl RMI 422 Manual De Instrucciones página 77

design: Lawn mower,
automatic and
cordless
manufacturer's STIHL
brand:
type: RMI 422.2
RMI 422.2 P
RMI 422.2 PC
serial number: 6301
design: Docking station
manufacturer's STIHL
brand:
type: ADO 402
Firmware V 2.00
serial number: 6301
complies with the relevant provisions of
Directives 2006/42/EC, 2011/65/EU,
2006/66/EC, 2014/53/EU and has been
developed and manufactured in
accordance with the versions of the
following standards valid on the date of
manufacture:
EN 50636-2-107, EN 60335-1 Ed 5, EN
55014-1, EN 55014-2, EN 61000-3-2, EN
61000-3-3
ETSI EN 301 489-1 V 2.2.0 (2017-03)
ETSI EN 301 489-3 V 2.2.1 (2017-03)
ETSI EN 303 447 V 1.1.1 (2017-09)
Additionally for RMI 422.2 PC:
ETSI EN 301 489-52 V 1.1.0 (2016-11)
ETSI EN 301 511 V 12.5.1 (2018-02)
ETSI EN 303 413 V 1.1.1 (2017-12)
The notified body TÜV Rheinland LGA
Products GmbH, No. 0197, has reviewed
the conformity according to Annex III
Module B of the Directive 2014/53/EU and
0478 131 9263 B - EN
issued the following EU type examination
certificate:
RT60151936 0001
Storage of technical documentation:
Andreas STIHL AG & Co. KG
Product approval
The year of manufacture and machine
number (serial number) are indicated on
the machine.
Waiblingen, 02.11.2020
ANDREAS STIHL AG & Co. KG
p.p.
Dr. Jürgen Hoffmann, Head of Product
Data, Product Regulations and Approval
23. Technical specifications
RMI 422.2, RMI 422.2 P, RMI 422.2 PC:
Serial number 6301
Mowing system Mulching mow-
ing deck
Cutting utilities Cutter bar
Cutting width 20 cm
Speed of cutting
utilities 4450 rpm
Battery type Lithium-ion
Battery voltage U 18,5 V
DC
RMI 422.2, RMI 422.2 P, RMI 422.2 PC:
Cutting height 20 - 60 mm
Protection class III
Type of protection IPX4
In accordance with Directive 2006/42/EC
and the EN 50636-2-107 standard:
Measured sound
power level L 60 dB(A)
WA
Uncertainty K 2 dB(A)
WA
L + K 62 dB(A)
WA WA
Sound pressure level
L 52 dB(A)
pA
Uncertainty K 2 dB(A)
pA
Length 60 cm
Width 43 cm
Height 27 cm
RMI 422.2:
Power 60 W
Battery designation AAI 50.1
Battery power 52 Wh
Battery capacity 2,4 Ah
Weight 9 kg
RMI 422.2 P:
Power 60 W
Battery designation AAI 100.1
Battery power 104 Wh
Battery capacity 4,9 Ah
Weight 10 kg
RMI 422.2 PC:
Power 60 W
Battery designation AAI 100.1
Battery power 104 Wh
Battery capacity 4,9 Ah
Weight 10 kg
Mobile radio:
75
