11.8 More
1. Lock iMOW®:
Activates the disabling device.
Press the illustrated button combination to
unlock. ( 5.2)
2. Edge mowing:
Following activation, the robotic mower
mows the edge of the mowing area. After
completing one circuit, it travels back to
the docking station and charges the
battery.
3. Settings ( 11.9)
4. Information ( 11.18)
11.9 Settings
0478 131 9263 B - EN
1. iMOW®:
Adapt machine settings
( 11.10)
2. Installation:
Adapt and test the installation
( 11.13)
3. Safety:
Adapt the safety settings (
4. Service:
Maintenance and service (
5. Dealer area:
The menu is protected by the
dealer code. Your specialist
dealer performs a variety of maintenance
and service operations with the aid of this
menu.
11.10 iMOW® – machine settings
1. Mow plan type:
Standard: The robotic mower mows the
lawn throughout the entire active time.
Mowing operations are only interrupted for
charging. The mow plan type Standard is
preset.
Dynamic: The number and duration of
mowing and charging times are adapted
fully automatically within the active times.
2. Rain sensor:
The rain sensor can be set so that
mowing is interrupted or does not
start when it is raining.
● Setting the rain sensor (
3. Status screen:
Select the information that is to
appear in the status screen.
( 11.2)
● Setting the status screen (
4 Time:
Set the current time.
The set time must correspond to the
actual time in order to prevent inadvertent
mowing by the robotic mower.
RMI 422 PC:
The time can also be set using the
app. (
11.16)
5 Date:
Set the current date.
11.17)
The set date must correspond to the
actual calendar date in order to prevent
inadvertent operation of the robotic
mower.
RMI 422 PC:
The date can also be set using the
app. (
6. Date format:
Set the required date format.
7. Language:
Set the required display language.
The language selected during initial
installation is set as the default.
8. Contrast:
The display contrast can be
adjusted as required.
9. Energy mode
(RMI 422 PC):
In Standard, the robotic mower is
connected to the Internet at all times and
can be reached using the app. (
In ECO, radio communication is
deactivated during rest periods to reduce
11.11)
energy consumption; the robotic mower
cannot be reached using the app. The
most recent available data is shown in the
app.
11.12)
10.)
10.)
10.)
45
