Close the flap of the robotic
mower. ( 15.2) Only once the flap has
been closed does the robotic mower start
automatically and follow the edge along
the perimeter wire.
RMI 422 PC:
Edge following is used to define the
home area of the robotic mower.
( 14.5)
If the robotic mower is not receiving
a GPS signal before starting edge
following, the text "Waiting for GPS"
appears on the display. The robotic
mower starts edge following after a
few minutes despite no GPS signal
being received. The "Test edge"
function ( 11.13) must be
executed later in order to use GPS
protection, as otherwise no home
area is defined.
As the robotic mower follows the edge,
walk behind it and ensure
– that the robotic mower follows the edge
of the mowing area as planned,
– that the clearances to obstacles and the
borders of the mowing area are correct,
– that docking in and out takes place
correctly.
0478 131 9263 B - EN
The distance covered is shown on the
display – this metric specification is
required for setting starting points at the
edge of the mowing area. (
● Read off the displayed value at the
required location and write it down.
Manually set starting points after initial
installation.
The following of edges is automatically
interrupted by obstacles, during operation
on excessively steep slopes or by pressing
the STOP button.
● If edge following has been interrupted
automatically, correct the position of the
perimeter wire and remove any
obstacles.
● Check the position of the robotic mower
before continuing edge following. The
machine must either be located on the
perimeter wire or within the mowing
area with the front facing the perimeter
wire.
Continuation following interruption:
After an interruption, continue edge
following with OK.
It is recommended by STIHL not to
interrupt edge following. Possible
problems when following the edge
of the mowing area or when
docking may not be recognised.
Edge following can be repeated
following initial installation if
necessary. ( 11.13)
The robotic mower docks after one
complete circuit around the mowing area.
The system then queries as to whether a
second edge following run in the opposite
direction should be started.
Automatic completion of edge
following:
The next step of the installation assistant is
11.14)
called up when the robotic mower docks
following the second complete circuit or if
edge following in the opposite direction is
refused.
9.13 Programming the robotic mower
Enter the size of the lawn and
confirm with OK.
Installed no-go areas and
secondary areas must not be
included when calculating the size
of the mowing area.
