– Viewing and editing the mowing plan
– Starting mowing
– Switching automatic mowing on and off
– Sending the robotic mower to the
docking station
– Changing the date and time
Changing the mowing plan, starting
a mowing operation, switching
automatic mowing on and off,
sending the robotic mower home
and changing the date and time can
result in activities that will not be
expected by other people. Affected
people must therefore always be
notified in advance about possible
activities of the robotic mower.
– Calling up machine information and the
location of the robotic mower
11. Menu
11.1 Operating instructions
40
The control pad comprises four direction
buttons (1). It serves for navigation in the
menus. Settings are confirmed and menus
opened using the OK button (2). Menus
can be exited again using the Back
button (3).
The main menu comprises 4 submenus,
displayed as buttons. The selected
submenu has a black background and is
opened using the OK button.
The second menu level is displayed as a
list. You move up and down through the
submenus by pressing the control pad.
Active menu entries have a black
background.
The scroll bar at the right edge of the
display indicates that further entries can be
displayed by pressing the control pad
downwards or upwards.
Submenus are opened by pressing the OK
button.
The "Settings" and "Information"
submenus are shown as tabs.
The tabs can be selected by pressing the
control pad to the left or right, submenus
by pressing the control pad downwards or
upwards. Active tabs and menu entries
have a black background.
Options are listed in the submenus. Active
list entries have a black background.
Pressing the OK button opens a selection
or a dialog window.
