Charging Guidance
1
ROV & Remote Controller
EN
· Charger (25.2V)
· The red light on the charger indicates normal charging, and the green light indicates
completion of charging.
· Please unplug the charger immediately after charging.
Charging time varies depending on environmental factors and actual results may vary.
2 E-Reel
Red light indicates Charging, green light indicates full charged.
Specifications
ROV
608x294x196mm
Size
(Excluding the floodlight)
Weight ≈8KG
200m
Maximum Depth
Pull (forward/drift
5.7/4.0/3.6kg
upwards/traverse)
Maximum battery life ＞4h
302.4Wh
Battery
-10℃~45℃
OperatingTemperature
Sensor
Three-axis gyroscope
IMU acceleration
compass
Depth Sensor ＜±0.25m
Temperature Sensor ＜±2℃
LEDLights
Brightness 2 x 4000lm
Color Temperature 5000K~5500K
CRI 85
Dimming Three adjustable
13
Camera
CMOS 1/2.3' '
Aperture f/2.8
Focal Length 0.3m~∞
ISO Range 100-6400
Field of View 150°
Maximum Image
12M
Resolution
JPEG/DNG
Image File Types
UHD:3840*2160 (4K) 30fps
FHD:1920*1080 (1080p)
Normal video
30/60/120fps
720p： 8x (240fps)
Slow motion video
1080p： 4x (120fps)
Time-lapse video 4K/1080p
Video Maximum Stream 60M
Video Type MP4
micro SD Card Memory 128G
Adapter
Adapter 8A /25.2V
ROV Charging time 2.5H
Remote controller charging time 2H
E-Reel
SIZE 296x189x279 mm
WEIGHT 3.5kg
MAX STORAGE LENGTH 200 meters
BATTERY CAPACITY 4800mAh
NUMBER OF CYCLES >300 times
RUNTIME 30 times
WIPING SPEED 3 gears
TAKE-UP SPEED Fast Speed 220s ；
（200m） Low Speed 9min
OPERATING
-10℃~45℃
TEMPERATURE
2H （12V ） /4H （25.2V ）
CHARGING TIME
Maintenance and Precautions
1
Navigation Safety
Open sea Relatively clear
navigation water quality, no
dense seaweed
2
Battery Protection
Do not run out Charge when
of battery power power is less
than 25%
3
Charging Protection
·Only use the Chasing standard adapter.
·Red light means charging.
·Green light means fully charged.
Remote Controller
Size 160x155x125mm
Weight 685g
Battery capacity 2500mAh
≥6H (Depend on
Battery life
working condition)
Wi-Fi support
Wi-Fi
support
HDMI
support
USB
Maximum support
Phone/tablet clip
10 inches
200m
No dense radio Do not dive
or radar signals more than
200m
Working
temperature
When not in use,
-10 °C ~ 45 °C
keep battery power
( -18°F-113°F)
at 50% - 70%
