Operation
Sleep mode
• The Sleep mode will give you an undisturbed and
comfortable sleep. The appliance operates quietly in a
special sleep program and the lights of the control panel
will be switched off 5 seconds after the mode is selected.
• To select the Sleep mode, press the
will show the temperature to be reached. To change the
desired temperature press the
• After the Sleep mode is activated, the desired (selected)
temperature will increase by 1°C 60 minutes after the mode
is selected, and by another 1°C after an additional 60
minutes. This new temperature will be automatically
maintained for 6 hours before it returns to the originally
selected temperature in Auto mode.
• In this mode, the exhaust hose must be used to let the hot
air out.

5.1.6 Standard modes

Air conditioning mode
This mode is ideal for hot and humid weather when the room
needs to be cooled down.
• In Air conditioning mode, the desired temperature and the
fan speed can be selected.
• To correctly set this mode, press repeatedly the
until the indicator lights up. The display will show the
temperature to be reached. To change the desired
temperature press the
desired fan speed, press repeatedly the
available air flows are:
– Minimum air flow: for silent operation.
– Medium air flow: for a good balance between noise and
cooling performance
– Maximum air flow: for maximum cooling performance
and fast cool down.
• In this mode, the exhaust hose must be used to let the hot
air out.
The most suitable temperatures during the summer range from
24 to 27°C. It is recommended to set the desired indoor
temperature no less than 6°C below the outdoor temperature.
On particularly hot days the temperature difference can be
increased, but should not exceed 10°C.
Dehumidification mode
This mode is ideal for reducing humidity in the room (spring and
autumn, humid rooms, rainy periods, laundry drying, etc.).
• To correctly set this mode, press repeatedly the
until the dehumidification indicator appears.
86
button. The display
or button.
button
or button. To select the
button. The
button
• The fan speed cannot be selected. The appliance will
automatically select the best air flow.
• The display will show the room temperature.
• Keep doors and windows closed to achieve the best
dehumidifying effect.
For dehumidification purposes, it is not required to use the
exhaust hose to let the hot air out. However, if a cooling effect is
also desired, it is recommended to attach the exhaust hose to
let the hot air out.
This appliance is provided with an auto-evaporation feature for
condensate removal during air conditioning and
dehumidification mode.
Note: in case of high ambient humidity, it is possible to drain
the condensate continuously by applying the hose supplied to
the upper drainage hose ( Chapter 6.3.1 "Continuous
drainage", Page 93).
Fan mode
• To correctly set this mode, press repeatedly the
until the fan indicator
flow, press repeatedly the
flows are:
– Minimum air flow: for silent operation.
– Medium air flow: for a good balance between noise and
air flow.
– Maximum air flow: for maximum air flow.
• The display will show the room temperature.

5.1.7 Swing function

This function moves the air outlet flap on the top panel up and
down to evenly distribute the air into the room. The function can
be activated in each mode.
• Press the button to enable the swing function. The air
outlet flap will begin to move up and down alternatively.
• If the button is pressed again, the flap will be locked into
its current position.
• If the button is pressed again, the flap will start to move
up and down again.
Note: in order to avoid damaging the internal mechanism, do
not move the flap manually!
Cool 4000 – 6721858458 (2023/04)
lights on. To select the desired air
button. The available air
button
