External view

■
EN-15
Unit : in (mm)
5.7"(146)
6.4"(162)
6.9"(175)
6.4"(162)
5.7"(146)
3.9"(100)
11"(280)
8
4
INSTALLATION OF BATTERY KIT
( TCB-BT1UPUL )
• Be sure to use with the battery kit TCB-BT1UPUL (sold separately).
• Do not connect anything except TOSHIBA CARRIER Battery kit.
• This kit includes a nickel-metal hydride battery (NiMH). For your safety, please read Instruction Manual
in Battery kit carefully and handle it with care.
• Do not touch this kit for at least 1 minute after disconnecting power supply at servicing.
1. Remove the four screws in the center of the maintenance cover, and then loosen the four screws on each side
to remove the maintenance cover.
2. Loosen the cover mounting screws (2 positions) of the electrical control box, and then remove the cover.
3. Install the Battery kit with the two screws (accessory of Battery kit) in the orientation shown in the figure.
When installing the Battery kit, be careful not to let the Battery kit contact the P.C. Board of Shut-off Valve box
and do not pinch the wires with the Battery kit.
4. Connect the connector of the Battery kit to CN521 (RED) on the P.C. Board of the Shut-off Valve box, which
is located on the right side when viewed from the Battery kit.
5. Turn on the No.4 DIP switch of SW03 on the P.C. board where the connector is connected.
Screw
for maintenance cover
(only loosen)
Battery kit
Screw Screw (Accessory)
Maintenance cover
Screw
Screw
Battery kit
(Accessory of Battery kit)
CAUTION
Do not pull the wire too hard. The connector inside the Battery kit may come off.
Electriacal control box
Screw
for maintenance cover
(only loosen)
Screw
for electriacal control box cover
(only loosen, two locations on the left and right)
Electrical control box cover
Clamp to the wire clamp. Connect to CN521
P.C. Board
Switch only the No.4 DIP
ON
switch of SW03 is ON.
1 2 3 4
SW03
