Do not arbitrarily bend or stretch the exhaust hose. This will
affect the cooling efficiency. However, the hose can be
moderately compressed and tensed according to the actual
installation needs.
The hose can be compressed to 300 mm minimum and
extended up to 1500 mm maximum. It is recommended to keep
the hose length to a minimum length.
Fig. 6
4.3

Casement window

1. Position the exhaust hose outside the window to let the hot
air out.
Fig. 7
Cool 2000 – 6721858239 (2023/04)
4.4

Hung/sliding window (adjustable window kit)

1. Depending on the need, cut the self-adhesive foam strips to
the desired length and attach them to the window sash and
frame.
Fig. 8
0010047562-001
2. Position the extendible window slider on the window and
fully extend it inside the window frame.
For the hung window, the portion of the window slider with the
greater depth should be placed along the bottom.
For the sliding window, the hole should be in the lower part to
allow a correct installation of the exhaust hose.
3. Adjust the extendible window slider depending on the
window size and fix the length by tighten the screws.
If the extendible window slider is too large, it is possible to cut
the plastic using a saw. This operation must be carried out by a
qualified professional.
0010047566-001
Installation
0010048793-001
