WIRING DIAGRAM FOR LOW CLEARANCE CEILING RECESS KIT
2300W/3400W (FOR USE WITH 2 HEATERS ON/OFF OR DIMMER)
BELOW IS A SIMPLIFIED DIAGRAM OF THE TERMINAL BOX.
ALL CONNECTIONS ADJUSTED BY THE INSTALLER ARE DISPLAYED.
ITEMS NOT DISPLAYED SHALL NOT BE MODIFIED.
Output 1
To Dimmer Power (Load) Output
To
OR ON/OFF Power (Load) Output
WARNING
AC Single Phase Heater
must be permanently
installed and hard wired
by an authorised/licensed
person.
This product is designed for use
with both 220-240V & 208V
Platinum Electric Heaters.
NOTES:
• For wiring instructions using Bromic SmartHeat Dimmer(s) or ON/OFF Controller(s) refer
to the instructions provided with the controller.
• *The junction box and connections inside must be suitable for the voltage and current
capacity of the heaters being installed.
HEATER
CABLE 1
S2
N2
L
S1
N
OR
OR
OR
OR
WIRES
DENOTED BY
DASHED LINES
ARE SUPPLIED
BY THE
INSTALLER.
To To Dimmer Power (Load) Output
OR ON/OFF Power (Load) Output
Input 1
To Dimmer Power Supply Input To
OR ON/OFF Power Supply Input
BROWN BLUE
LIVE/ACTIVE
NEUTRAL
HOT LEG 1
HOT LEG 2
PHASE A
PHASE B
PHASE B
PHASE C
PHASE C
PHASE A
bromic.com
S2
N2
S1
Output 2
JUNCTION
BOX*
SUPPLY
GREEN/
YELLOW
EARTH
US ONLY
240V OR 208V
HEATER
CABLE 2
L
N
