Control Pro 350 Extra Cart
Under pressure, the nozzle may be very difficult to turn. Turn the switch to the PRIME position (vertical) and pull the
i
trigger. This will relieve pressure and the tip will turn more easily.
2. Turn the switch to the SPRAY position (horizontal).
3. Unlock the gun and squeeze the trigger, pointing the gun at a scrap piece of
wood or cardboard. This allows pressure in the spray hose to blow out the
obstruction. When the nozzle is clean, material will come out in a straight, high
pressure stream.
4. Release the trigger and secure the gun. Reverse the nozzle so the arrow
points forward again. Unlock the gun and resume spraying.
The HEA Filter Set keeps nozzle blockages to a minimum (see "HEA Filter Set").
i
HEA Filter Set
Assembly
The gun and high-pressure hose must be de-pressurised before
the filter set is installed / removed.
Danger
1. Disconnect the high-pressure hose from the gun (1).
2. If necessary, screw on the filter housing (2) and insert a filter (3) appropriate
to the nozzle (the conical side (A) must point upwards).
Nozzle 311 Filter red
Nozzle 517 / 619 Filter white (pre-installed in the filter housing)
3. Screw the filter housing (2) to the gun (1).
4. Screw the high-pressure hose (4) firmly to the filter housing (2).
Cleaning
The gun and high-pressure hose must be de-pressurised before
the filter set is installed / removed.
Danger
1. Remove the filter housing (2) from the hose (4) and the gun (1).
2. Screw on the filter housing (2) and remove the filter (3).
3. Thoroughly clean the filter (3) and filter housing (2) (if worn, replace the filter).
4. During reassembly, take care not to lose the seal and spring.

Interruption of Work

Be sure to follow the Pressure Relief Procedure when shutting the unit off for any purpose.
This procedure relieves the pressure from the spray hose and the gun.
Watch the pressure gauge ––> 0 bar
Danger
•
Switch the device off (pressure regulator in position 0) and remove the power plug.
•
Put the spray gun in a plastic bag and seal so that it is air-tight.
•
Wet paint surface in paint container with a little water to prevent a skin from forming.

Taking Out of Operation and Cleaning

Proper cleaning is the prerequisite for problem-free operation of the paint application device. No warranty claims are accepted
in case of improper or no cleaning.
Do not use flammable materials / cellulose thinner for cleaning purposes.
Danger
Always clean the device as soon as you have finished operation.
i
Dried-on coating substance makes cleaning more difficult.
2
4
GB
1
A
3
25
