1 Safety
Warning indications
Where applicable, the following warning indications are used in this
manual in connection with safety:
Indicates that great potential danger exists that can lead to serious
injury or death.
Indicates that a potential danger that can lead to injury exists.
Indicates that the usage procedures, actions etc. concerned can re-
sult in serious damage to or destruction of the engine. Some CAU-
TION indications also advise that a potential danger exists that can
lead to serious injury or death.
Emphasises important procedures, circumstances etc.
Symbols
Indicates that the relevant procedure must be carried out.
Indicates that a particular action is forbidden.
Share these safety instructions with all users.
General rules and laws concerning safety and accident prevention
must always be observed.
This product should only be installed and maintained by
qualified personnel who have read and understood the in-
structions and precautions in this manual. Failure to follow
the instructions in this manual may result in serious injury or
property damage. The manufacturer shall not be liable for any
damages resulting from improper installation or maintenance
by unqualified personnel.
This product should only be operated by persons who have
read and understood the instructions and precautions in this
manual. Failure to follow the instructions in this manual may
result in serious injury or property damage. The manufacturer
shall not be liable for any damages resulting from improper
operation.
4
070112.02
D
anGer
W
arninG
c
aution
n
ote
W
arninG
W
arninG
Escape hatch handles must be unlocked when sailing. See draw-
ing 1 (B).
2 Introduction
This manual applies to the following VETUS Flybridge hatch.
For drawings see pages 14-15.
3 Fitting
N.B.: The highest permitted design category or the highest permitted
area of use is stated on every hatch.
When fitting the hatch, take the following into account:
- The hatch must open outward.
- Fit the hatch on a completely flat surface! The hatch will never be
watertight when closed if fitted on a curved surface!
- First, fill out the curved surface with a close-fitting wood frame.
- It is not possible to check that the hatch is watertight until it has
been completely built into the ship.
- When the hatch has not been fitted in the ship, the opening and
closing of the hatch can damage the aluminium frame and/or
hinges when the hinges have been adjusted very tight!
• Draw the hole to be cut out using the hatch deck frame.
All VETUS hatches are manufactured with a corner cutout radius
of 43 mm (1 11 / ").
16
The hatch is recessed into the deck so that the top of the acrylate
window will lie level with the deck.
Take the dimensions given in drawing 5 into account when deter-
mining the dimensions of the part recessed into the deck.
At least 1 water outlet must be made at the lowest point of the
recessed part of the deck.
• Cut the hole in the ship by sawing for polyester, aluminium or
wood, or by acetylene cutting for steel. Remove all burrs carefully
and smooth the edges.
Dust released when cutting and sanding glass-fibre reinforced
polyester is hazardous to lungs and eyes. So always wear a dust
mask and goggles when working with this material. Ventilate
the working area well.
• Position the hatch over the cut hole and mark the fixing holes for
the frame, see Drawing 3. Drill the holes and remove any burrs.
• Apply a sufficient amount of sealant to ensure a good seal, see
Drawing 4. Position the hatch on deck.
• Fixing the frame to the deck - deck material:
n
ote
W
arninG
