ASSEMBLY
To close the WSUV stand:
 At the same time, step on the release lever, grasp the
grips, and lift the handles up and away from the body.
 Push the inner leg assembly until the release lever clicks
and locks into place.
To move the WSUV stand:
 Holding the grips firmly, pull the handles toward you until
the WSUV stand and saw are balanced on the wheels.
 Push the saw to the desired location then either open the
WSUV stand for saw operation or store the saw in a dry
environment.
INNER LEG
ASSEMBLY
To open the WSUV stand:
 Step on the release lever and pull the grips toward you
at the same time.
 Once the WSUV stand is released from the release lever,
ease the WSUV stand toward the floor by pushing the
grips toward the floor.
 With your hands on the grips, push the WSUV stand
towards the ground until the saw is in an open position.
NOTE: The release lever will close over the pin locking
the WSUV stand in an open position.
Fig. 35
23 — English
Fig. 36
