Machine elements

1 2
10
Abb. 9: Machine elements
Mains cablel
1
Mains switch
2
Connector remote control
4
(Handy 200 400V 3~ RC)
Front panel
5
Shoulder strap
6
Connector positive pole
7
Connector negative polel
8
Air intake
10
- 26 -
4 5 6
8 7
