RE MO T E CON TRO L CO NNECT I O N
Insert the remote control controller into the mounting bracket as shown in the picture.
MOU N T I NG THE F I NIA L
1
1. Lift the finial up to the mounting bracket and align the loosened screws in the mounting
bracket with the holes in the finial.
2. Turn the finial to adjust and reinsert the screws.
3. Secure the screws with the help of a screwdriver.
4. Then lift the decorative cover towards the rosette so that it is fixed with the built-in magnet.
Advice: Another person should help you hold the ladder and hand you the fan once you are
on the ladder.
C H EC K TH E I N STALL AT I O N
• Check that the ceiling fan is working properly, checking that no strange movement or mis-
alignment is observed in any part of the fan.
• If any type of humming/vibration can be noticed, you can proceed to adjust the blades with
the anti-sway kit.
• The anti-sway kit features self-adhesive counterweights and "u" shaped clips.
• Turn off the ceiling fan.
• You can put the clip in the center of any blade and check if the vibration decreases.
• Turn on the fan and check. If no change is seen, turn off the fan and add another clip to
another blade or use the adhesive counterweights.
2 3 4
