Chain oil supply
Chain oil can lubricate and cool the chain. This chainsaw does not have an internal oil tank. To
lubricate the chain use the supplied oil transfer bottle by spreading a few drops of oil on the
chain. To distribute the oil over the entire chain, run the chainsaw „idle" so that the chain carries
the oil along its entire length. During this operation, the chain must not be in contact with any
object.

Checking the chainsaw

Turn off the power when doing the following.
Chain wheel inspection
1. Turn off the chainsaw and remove the battery.
2. Remove the protective cover of the chain wheel.
3. Remove the bar and the chain.
4. Measure the depth of the chain wheel groove using a
depth gauge. (see image below)
5. If the groove depth is not above 0.5 mm, do not use the chainsaw and contact your dealer
or Stocker Srl to request spare parts to replace the chain wheel as soon as possible.
Bar inspection
1. Turn off the chainsaw and remove the battery.
2. Remove the chain and the bar.
3. Replace with a new bar if the following conditions are present:
a. The bar is damaged.
176
Art. 320
Chainsaw ALL-ROUNDER E-100 UC
Assembly
Art. 320
Chainsaw ALL-ROUNDER E-100 UC
Assembly
b. The measured depth is less than the minimum permissible depth.
c. The chainsaw groove is deformed and damaged.
4. Please contact your dealer or Stocker Srl to request spare parts.
Start-up inspection
1. Make sure that nobody is within 15 metres of the workplace and watch out for animals.
2. tAlign battery „1" with the battery compartment of the chainsaw and push it in until it
locks and makes a click.
3. Start the chainsaw by pressing the power button „2" for 0.5 seconds until the LED lights
up. Hold the chainsaw „3" in your hand, press the self-locking switch „4" with your thumb
and pull the trigger „5". The chainsaw will start normally. (Note: The chain and the bar must
not come into contact with any object when starting the machine.)
4. Press the power button „2" for 0.5 seconds to turn off the chainsaw. The machine will
enter power-saving mode 3 minutes after inactivity and turn off.
For further information about the product, please contact info@stockergarden.com
