X9 125-180 ce 4T4V
Checking the crankshaft alignment
Maximum allowable misalignment: A = 0.15 mm
Bearing and crankcase half classes
Crankcase half Axle shaft
Class 1
Class 2
Class 1
Class 2
Β = 0.01 mm
C = 0.01 mm
D = 0.10 mm
Bearing
Class 1 Β
Class 2 Β
Class 2 A
C
Class 1
Vehicle overhaul data
TYPE COLOUR CODING
A
Β
C
1 st Update to part no. 594599 X9 125-180 cc 4T 4V 1 - 31
Primera actualización dib. 594599 X9 125-180 cc 4T 4V
1 ' Atualização Des. 594599 X9 125-180 cc 4T 4V
01 011
01 012
Red
Blue
Yellow
