PIAGGIO X9 Manual Para Talleres De Servicio página 28

X9 125-180 CC4T4V
WEIGHT AND DIMENSIONS
Total dry weight
Width (at mirrors)
Length
Wheelbase
Height
ENGINE
Type Single-cylinder, four-stroke, four-valve.
Cooling system
Number of cylinders
Bore 57 mm (125 cc); 69 mm (180 cc)
Stroke
Displacement .. 124.2 cm
Compression ratio
Timing system
Play of valves: intake
exhaust
Walbro Carburettor
Idle speed
CO adjustment
Air filter , ..,,
Λ
jr
Starter system
Engine lubrication
Fuel system
Max. power (crankshaft):
125 cc
180 cc 14.7 kW (20 HP) at 8500 rpm
Top speed
ELECTRICAL COMPONENTS
Ignition type
Spark advance
(before TDC) variable, microprocessor-controlled
(125 cc)
(180 cc)
Spark plug
Battery
Fuses N2 10A, N2 15A, N2 10A, N1 7.5A, N1 5A
Generator three-phase alternating current.
CAPACITIES
Fuel tank (including -2.5 I reserve)
Engine oil
(recommended oil: Selenia HI Scooter 4 Tech)
159 Kg
865 mm
2100 mm
1495 mm
1350 mm
Liquid cooled
48.6 mm
3 3
(125 cc); 182 cm (180 cc)
11.5 + 13 :1 (125 cc)
11.5+ 12.5: 1 (180 cc)
Single overhead camshaft
driven by chain on left side,
three-arm rockers with
threaded adjuster.
0.10 mm
0.15 mm
WVF7C 0 29 mm (125 cc)
WVF7D 0 29 mm (180 cc)
(Identification letter may be
changed every time carbu-
rettor is updated).
1650±50 rpm
3.8 ± 0.7 %
Sponge impregnated with
50% oil (Selenia Air Filter oil)
and 50% unleaded petrol.
electric starter motor (180 cc
engine with torque limiter).
lubrication with chain driven
lobe pump in crankcase,
mesh strainer and cartridge
filter.
by carburettor, with electric
fuel pump.
11 kW (15 HP) at 9700 rpm
104 Km/h (125 cc)
118 Km/h (180 cc)
Electronic capacitive dis-
charge system with separate
HT coil.
from 10° ± 1° at 2000 rpm
to 34° ± 1 ° at 6000 rpm
from 10° ± 1° at 2000 rpm
to 32° ± 1 ° at 6000 rpm
NGK CR 8 EB
12V-12Ah
~ 14.5 I
~ 1000 cc
Cooling system
(Recommended fluid: diluted PARAFLU 11FE)
Rear hub
(recommended oil: TUTELA ZC 90)
FRAME AND SUSPENSION
Type
Front suspension
1
Front fork travel
Rear suspension
Rear wheel max. travel
BRAKES
Front (right side).
Combined.
WHEELS AND TYRES
Lightweight alloy wheels: front
Tyres: front
rear:
Tyre pressure (cold): front:
1 st Update to part no. 594599 X9 125-180 cc 4T 4V 1 - 1 9
Primera actualización dib. 594599 X9 125-180 cc 4T 4V
Specifications
Welded steel tubing with
pressed steel reinforce-
ments.
hydraulictelescopicforkwith
0 35 mm rod.
Rear engine suspension
functioning as double-sided
swingarm pivoting on frame.
Double-acting
shock absorbers, variable-
pitch coaxial spiral spring
with 4-position preload ad-
justment.
. Disc brake, diameter of 240
mm with hydraulic linkage
(right-hand brake lever) 0
34 mm single-piston caliper
dual disc 0 240 (front left
and rear) with hydraulic con-
trol operated by left-hand le-
ver on handlebar. The sys-
tem is slave to a pressure-
distributing valve 0 32 mm
single-piston caliper.
Front sx
Resar
rear
120/70-14" 55P
* 140/60-14" 64P
rear:
(2.5 bar with driver and luggage)
1 · Atualização Des. 594599 X9 125-180 CC 4T 4V
~ 1.2 It
~ 150 cc
94 mm
hydraulic
93 mm
0 32 mm
0 32 mm
3.50x14"
3.50x14"
2.1 bar
2.3 bar
